How to separate the bad sectors on the hard drive with Minitool Partition wizard

. Download and install Minitool Partition Wizard here.

2. Once install it to the windows os and open the Minitool partition wizard and point to your mouse on the hard drive we will check the existence of the damaged sector.

3. Once we select the hard drive, right click on the mouse and select "Surface Test" to start checking for bad sectors wait until the check is finish.

4. The result will be to know before and after a hard drive on a check , if the color of the little boxes all the green , then the hdd ( hard drive ) there are no bad sectors or no block sector has been corrupted, and if the small box is red then it is block or sector is damaged .

After we check and find out the block sector has been corrupted then the next step is to separate partition bad sectors and should not be used in a way that damaged sector block, and even if bad sectors the disk is not too severe then we can use this step. Before we separate the bad sectors in affected partition we can use the other repair bad sector disk apps to recover/repair such as hdd regenerator or other tools recovered, and if it is not able to recover in the best way is to separate or cutting the blocks sectors are damaged.

How to separate the bad sectors on the hard drive with Minitool Partition wizard:

Following ways is a short but solid tips but block the damaged sector we do not know how  MB/GB  but here I use a feeling or a percentage of the hard drive.

1. Once scanned and checked for bad sectors and it is not too much then the next step on the way to unformat/unallocated partition the bad sectors affected.

2. Move/resize of size the partition and create a new partition for example if the disk is 2 gb and bad sectors are at the beginning of the partition such as in the picture above.

3. Cut that was the beginning of the partition by right-clicking the mouse on the minitool partition wizard and move/resize partitions as about 200 MB at the beginning of the affected or contained some bad sectors.

- Drag the mouse left click to start separating the affected partition bad sectors to the right .

- If it is determined that the capacity will be separated click apply button on the left of the software minitool

4. Once cut into two parts so that 2GB partition in pieces 200MB so the harddrive become 1.8 GB and the remaining 200MB, scan again or check back with "Surface Tests" if it is contained bad sectors.

5. If there are bad sectors on the new partition 1.8 GB and start cutting back the partition to approximate how many MB to be cut in this way is to use move/resize option on minitool partition wizard and so on until the bad sector is completely absolutely nothing in the new partition.

6. The new partition in bad sector affected must be to unformat or unallocated which means we don't use that partition so it does not interfere with the performance of other partitions.

Here's an example of the hard drive is a lot of bad sectornya so many separate partitions as shown below, indicates unalocated partition is not used because there are bad sectors .

But if bad sectors are in the middle of the 2GB partition?  cut into two parts for example if the disk is 2 GB Move/Resize in the middle 1GB and 1 gb check back with "Surface Test" and find the bad sector and use the step above.

The example above is not from the hard drive really bad sectors but it is just an example of how to separate the bad sector is like the example above. And I have tried to my hard disk with bad sector affected and can be quite successful.

I am so confused to how to explain it but hopefully my this post is understandable :).
